RSS 100 Scrap Shear


RSS 100R that was on rent for 1 month.
It comes with an 8 month warranty

Replaceable cutting knives
The RSS Series is fitted with replaceable cutting knives and completely encased nose knives. The jaw design ensures that the materials are forced deep into the jaws, where the highest cutting power is available. The RSS Series body is assembled from high-grade performance steel and wear-resistant materials, making it extremely strong.

Upper head and slewing ring
The RSS Series has a strong rotating upper head and a heavy-duty, double-rowed slewing ring. The hydraulic motor and the gearbox in the upper head generate a high torque, allowing the RSS Series to be moved in every possible position

Specially developed hydraulic cylinder
The hydraulic cylinder with integrated speed valve, developed by Rotar, allows the jaws to close quickly and the RSS will effortlessly switch from speed to power mode as soon as the job requires more cutting power

The double hose connection
The double hose connection on the swivel and large diameter of hoses, bores, and pipes creates optimum oil flow. This connection stops heat building up in the hydraulic system, reducing the RSS’ fuel consumption.


Additional Info:

RSS 100

Machine class (t) on boom 45 – 68
Machine class (t) on dipper 65 – 90
Weight (kg) * 8250
Dimension A (mm) 4835
Dimension B (mm) 947
Dimension C (mm) 903
Rotar Hole-pattern 200
Tip ** (D) (t) 242
Apex ** (E) (t) 467
Throat ** (F) (t) 1338
Max. operating pressure cylinder (bar) 350
Oil volume cylinder (L/min.) 500 – 750
Max. operating pressure hydromotor (bar) 170
Oil volume hydromotor (L/min.) 50
* Weight exclusive adapterplate with bracket
** Cutting force by 350 Bar
*** Technical specifications are subject to change without prior notice.
