The Monster EVO granulator is small and extremely efficient and can achieve 99.9% separation of plastics and metal in the first pass. We recommend adding a Turbo unit to increase your productivity by eliminating the need to pre-sort the wire and cable. The Turbo accessory may not be needed if you are only processing rigid cable.
The MG 150 is a compact copper granulator specifically built to recover copper from electrical cables while consuming minimal energy. This equipment is capable of processing 330 to 660 lbs. of material every hour. The MG 150 granulator has the ability to separate fine and rigid wire through a pulverizing and separation process, and has a self-cleaning mode that reduces maintenance and removes dust.
The MG 220 VZT is a high capacity wire granulating machine that recovers copper from just about any waste wiring component, including scrap of different specific gravities. Through its patented pulverizing system, the MG 220 VZT will process 1,100 to 1,300 lbs. of waste material every hour. The system is able to identify and separate thin wire from coarse rigid material and directs these to separate sections of the system for additional processing.
The MG 380 VZT processes between 1,765 and 2,650 lbs of material every hour. After pulverizing scrap, the MG 380 VZT granulator sorts materials of varying weights through airflow separation. The machine is designed to fully recover aluminum and copper materials from even the thinnest materials. Utilizing the Tritonic Pre-Shredder, the 380 VZT adjusts to the thickness of each material before conveying it to the granulator and separator, making it highly efficient. Just like other MG granulators, this model comes with a self-operated dust removal system for easier maintenance and a longer lifespan.
Fairly new
3′ extensions can be put on to double the capacity (for an extra charge)
Unit had a very large gear box
MG 610 VZT Cable Granulator – Unleash the Power of Maximum Production Capacity!
Looking to tackle large-scale wire recycling projects? Look no further than the MG 610 VZT Cable Granulator – the largest machine in the Matrix range, with an incredible production capacity of up to 4400 lbs per hour of infeed material.
This powerhouse of a machine can handle a wide variety of materials, including cables, fine wire, radiators, circuit boards, and other waste electrical scrap. With its immense capacity, the MG 610 VZT Cable Granulator ensures that you have more than enough material to feed and optimize its capabilities.
The Magnetic Drum Separator is normally installed at product discharge points and incorporates a 150 – 180 degree magnet system, encased in a stainless steel shell, or manganese wear plates for severe application.
This system pulls iron contamination out and behind the clean product path and discharges it automatically while the clean product continues its normal trajectory.
Whether you are in the Plastic, Electronic, Tire, Paper, Metal, or Wood Recycling business, the cross-belt magnets do a great job of separating ferrous metal contamination from non-ferrous products. They are also an ideal means of cleaning the product stream for equipment protection on shredded plastic being conveyed between Shredders and Granulators to protect against costly knife damage and maximize product purification.
These units can also be designed into “custom systems” in combination with the Transfer or Pick Conveyors with Stainless Steel bed sections or over Vibratory Trays for optimum separation. Bunting Engineers will provide full 3D System CAD Models and 2D dimensional drawings for system review analysis when orders are placed.
The machine is basically split in two. The hydraulic press or cracking/splitting platform is separate from the copper extraction platform. Each unit has its own motor and can be independent of the other. See the pictures below. The dimensions of each platform are 47 inches by 27 inches by 86 inches, 1,800 pounds for the cracking/splitting platform and 70 inches by 41 inches by 82 inches 2,700 pounds for the copper extraction platform.
Triple platform – This setup is three separate platforms: two hydraulic presses and one copper extraction platform. One press is for cracking the cast, one press is for splitting the stators, and the final platform extracts the copper.
All the different setups have the same components to service the same function. The more platforms you have, the quicker the process is and the more production you can handle.
Steel conveyor belt new less than 1,000 hours used for paper only, rails, liners refurbished less than 1,000 prior to be being removed from service.
Maxxforce 7 Engine
46,740 miles
33,000 gvw
21,000 lb front axle
23,000 lb rear axle
Allison 2500 Automatic Transmission
Alpine Shredder # is 512V-33-0001
Walking Floor
+/- 1,200 hours on shredder
1.5-2 tons per hour process speed
